- PCI-express 64Pin Slot.1.00 Pitch. W/Post. wall close style. Vert. DIP Type
NOTES:
1.MATERIAL SPECIFICATION
1-1.HOUSING: HIGH TEMPERATURE THERMOPLASTIC, UL94 V-0.
1-2.CONTACT: COPPER ALLOY T=0.25mm.
2.PLATING SPECIFICATION
2-1.CONTACT: NI30μ'' MIN. UNDER PLATED,GOLD FLASH PLATED ON
THE FUNCTIONAL AREA OF CONTACT, TIN 80μ'' MIN. ON SOLDER AREA.
1.MATERIAL SPECIFICATION
1-1.HOUSING: HIGH TEMPERATURE THERMOPLASTIC, UL94 V-0.
1-2.CONTACT: COPPER ALLOY T=0.25mm.
2.PLATING SPECIFICATION
2-1.CONTACT: NI30μ'' MIN. UNDER PLATED,GOLD FLASH PLATED ON
THE FUNCTIONAL AREA OF CONTACT, TIN 80μ'' MIN. ON SOLDER AREA.
